TROUBLESHOOTING PROCEDURES - CONTINUED
TEST OR INSPECTION
ENGINE - CONTINUED
10. Engine Overheats Water Temperature
Gage Indicates in Red Area.
DO NOT service cooling system unless
engine has been allowed to cool down. This is
a pressurized cooling system and escaping
steam or hot coolant may cause serious burns.
DO NOT remove cooling system radiator cap
when engine is hot. Allow engine to cool
down. Loosen cap to first stop and let any
pressure out of cooling system, then remove
cap. Failure to follow this warning may cause
Wear effective eye, glove, and skin protection
when handling coolants. Failure to do so may
problem still exists, go to test step
2. Inspect radiator for debris
blocking the air flow through
1. Check position of main
Place main disconnect switch in
11. Engine Fails to Crank When Power Switch
ON position. If problem still
Is Turned to Start.
exists, go to test step 2.
2. Check position of transmission
Place transmission range selector
range selector lever.
lever in N (Neutral). If problem
still exists, go to test step 3.
3. Check for dirty, loose, or
damaged battery cables.
Tighten loose connections. If
cable is damaged, notify
Inspect drive belt for damage or
