TM 10-3930-641-34-2
TRANSMISSION AND TRANSFER ASSEMBLY INSTALLATION (CONT)
LOCATION/ITEM
ACTION
REMARKS
36.
Two steering cylinder hoses (33)
Connect to steering control valve.
37.
Three pilot hose assemblies (34,
Connect to steering control valve.
35 and 36)
38.
Hydraulic supply hose (37)
Install to hydraulic pump and filter.
39.
Channel assembly (38)
a. Install.
40.
Handrail assembly
Install to right side of vehicle, if removed.
TA099273
Go on to Sheet 11
4-65
