TM 10-3930-641-34-2
FRONT AND REAR SUPPORT DISASSEMBLY/ASSEMBLY (CONT)
(Sheet 5 of 9)
LOCATION/ITEM
ACTION
REMARKS
12.
Rear support (35)
a. Attach to a floor jack.
b. Raise rear of vehicle with the two
hydraulic jacks (See Step 3) until pins in
the top of the support are free of vehicle
frame.
c. Remove rear support.
13.
Preformed packing (1)
Replace.
14.
Bearing (33)
Replace if damaged.
15.
Capscrews (20) and washers (21)
Remove from cover (19).
16.
Cover (19)
a. Attach to floor jack.
b. Use two 7/8-9NC capscrews as
forcing screws to loosen cover.
NOTE
Cover weighs 140 lb. (64 Kg).
c.
Remove cover from axle housing (13).
17.
Preformed packing (18)
Replace.
Go on to Sheet 6
4-300
