TM 10-3930-641-34-2
HYDRAULIC PUMP ASSEMBLY/DISASSEMBLY (CONT)
(Sheet 7 of 7)
LOCATION/ITEM
ACTION
REMARKS
NOTE
Using suitable drive plate and handle, install
seal until it makes contact with spacer ring.
Lip of seal must be toward inside of pump.
18.
Casting (3)
Place in position on gear plate housing.
19.
Four nuts (1)
Install.
NOTE
Place pump on small wooden blocks to allow
the studs in the casting to go through cover
plate without moving inside parts of pump
out of position.
20.
Four nuts (1)
Install.
NOTE
Use an arbor press to hold pump in position
while torquing nuts.
Tighten nuts to a torque of 280 to 320 lb. ft.
(379.6-433.9 N-m).
End
7-19
