TM10 3930-641-34-2
MAST REMOVAL/INSTALLATION (CONT)
(Sheet 4 of 5)
LOCATION/ITEM
ACTION
REMARKS
INSTALLATION I
1. Shims, wear pads, and sliding blocks
Check for wear and replace if worn thin.
2. Mast
a. Lift to upright position.
b. Guide to "J" hooks (3) and have eyes (4)
on either side of "J" hooks.
c. Lift mast up onto "J" hooks.
WARNING
Use appropriate safety equipment to secure
mast from falling forward
WARNING
Never place any part of your body under mast.
TA099175
Go on go sheet 4 of 5
7-74
