TM 10-3930-641-34-2
TOPHANDLER DISASSEMBLY/ASSEMBLY (CONT)
(Sheet 2 of
13)
LOCATION/ITEM
ACTION
REMARKS
DISASSEMBLY
1.
Container lock cylinder (78)
a. Tag and remove hydraulic lines.
b. Plug open lines.
c.
Remove front and rear clevis pins (39).
d. Remove cylinder.
2.
Force limiter assembly
a. Remove capscrews (12) and nuts (38).
b. Remove force limiter assembly from
frame assembly (3).
3.
Control rod limit switch (69)
a. Disconnect wiring at limit switch.
(56).
c.
Remove limit switch.
Go on to Sheet 3
9-4
