TM 10-3930-675-24-1
ENGINE ELECTRONIC CONTROL UNIT (ECU) (794) TROUBLESHOOTING - CONTINUED
0018 00
Table 4. Error Code 1352 - Sensor Voltage Supply Failure Troubleshooting Procedures - Continued.
MALFUNCTION
TEST OR INSPECTION
CORRECTIVE ACTION
Error Code 1352 - Sensor Voltage Supply Failure 10.Place ignition switch in OFF
- Continued.
position and disconnect sensor
harness from engine ECU,
ambient air pressure sensor,
and intake manifold pressure
sensor.
a. Measure resistance from If engine harness requires
sensor harness pin 17 to all replacement, notify Sustainment
other pins in sensor harness. Maintenance.
Resistance should be greater
than 100k Ohms.
b. Measure resistance from If engine harness requires
sensor harness pin 37 to all replacement, notify Sustainment
other pins in sensor harness. Maintenance.
Resistance should be greater
than 100k Ohms.
>100K OHMS
0018 00-16
