TM 9-3950-253-13&P
0110
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
DESCRIPTION AND USABLE ON
NO. SMR CODE
NSN
CAGEC
PART NUMBER
CODE (UOC)
QTY
GROUP 3307 SPECIAL PURPOSE
KITS
FIG. 16. E-CHU MOUNTING
HARDWARE AND BRACKETS FOR
HEMTT.
XDFZZ
34914
112130301
BRACKET,MANIFOLD MO........................... 2
1
PAFZZ
5310-00-080-6004
96906
MS27183-14
WASHER,FLAT 3/8" UNC GR8................. 16
2
PAFZZ
5305-00-725-2317
80204
B1821BH038C150N SCREW,CAP,HEXAGON H
3
3/8"X1-1/2" UNC GR8................................... 4
PAFZZ
5310-01-509-2488
81349
M45913/3-6CG8C
NUT,SELF-LOCKING,HE 3/8" UNC GR8... 4
4
PAFZZ
5305-00-781-3928
80204
B1821BH038C400N SCREW,CAP,HEXAGON H 3/8"X4"
5
UNC GR8...................................................... 4
PAFZZ
5305-00-071-2069
80204
B1821BH050C150N SCREW,CAP,HEXAGON H
6
1/2"X1-1/2" UNC GR8................................. 12
WASHER,FLAT 1/2" GR8......................... 24
PAFZZ
5310-00-809-5997
96906
MS27183-17
7
PAFZZ
5310-00-488-3889
81349
M45913/3-8CG8C
NUT,SELF-LOCKING,HE 1/2" UNC GR8. 12
8
PAFZZ
2590-01-573-5292
34914
112079001
BRACKET,VEHICULAR C............................ 2
9
PAFZZ
5340-01-573-5709
34914
112079302
BRACKET,MOUNTING MOUNTING
10
RT CHEMTT MIRRORED............................. 1
PAFZZ
BRACKET,MOUNTING MOUNTING
5340-01-573-7843
34914
112079301
10
LT CHEMTT SHOWN.................................... 1
PAFZZ
5305-01-566-3202
39428
92316A804
SCREW,SHOULDER 5/8"X2-1/2"
11
UNC GR8...................................................... 6
PAFZZ
5305-00-716-7606
80204
B1821BH056C200N SCREW,CAP,HEXAGON H
12
9/16"X2" UNC GR8........................................ 8
5310-00-809-3079
96906
MS27183-19
WASHER,FLAT 9/16" GR8......................... 8
PAFZZ
13
PAFZZ
5340-01-573-7769
34914
112090401
BRACKET,MOUNTING MOUNTING.......... 1
14
PAFZZ
5310-00-809-8533
96906
MS27183-23
WASHER,FLAT 3/4" GR8........................... 6
15
PAFZZ
5305-00-938-1539
80204
B1821BH075C200N SCREW,CAP,HEXAGON H 3/4"X2"
16
UNC GR8...................................................... 6
END OF FIGURE
