WP 0002 00
TM 10-3930-641-24P
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
SMR
PART
NO
CODE
NSN
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC) QTY
GROUP 0105 VALVES, CAMSHAFTS, AND
TIMING SYSTEM
FIG. 10 VALVE COVERS (LEFT-HAND AND
RIGHT-HAND)
1 PAOZZ 5330010695128 11083 5P5678
SEAL,PACKING PART OF KIT P/N 5P9839.
2
UOC:V53
2 PAOZZ 5306001651934 11083 9L8925
BOLT,MACHINE........................
40
UOC:V53
3 PFOZZ 2815012975382 11083 4W6822
COVER,ENGINE POPPET.................
2
UOC:V53
4 PAOZZ 5307011022485 11083 7M1599
STUD,PLAIN..........................
8
UOC:V53
5 PFOZZ 2815012975383 11083 7C9635
COVER,ENGINE POPPET.................
2
UOC:V53
6 XBOZZ 2815010512355 11083 4N0851
ADAPTER.............................
2
UOC:V53
6 PFOZZ
11083 76C514
ADAPTER.............................
2
UOC:V53
7 PAOZZ 2815010512334 11083 4N4957
PLUG................................
2
UOC:V53
7 PAOZZ
11083 7C9621
PLUG................................
2
UOC:V53
8 PAOZZ 5331012926888 11083 8C5196
O-RING USE WITH 7C6514 AND 7C9621..
4
UOC:V53
END OF FIGURE
