WP 0002 00
TM 10-3930-641-24P
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
SMR
PART
NO
CODE
NSN
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC) QTY
1 PAFZZ 5305000712055 80204 B1821BH044C150N
SCREW,CAP,HEXAGON H.................
4
UOC:V53
2 PAFZZ 5310010978955 11083 5P8244
WASHER,FLAT.........................
4
UOC:V53
3 PFFZZ 4730010515257 11083 1P4578
FLANGE,PIPE.........................
2
UOC:V53
4 PCFZZ 5331009484063 11083 4J0522
O-RING..............................
1
UOC:V53
5 PCFZZ 5331009136144 11083 4J0520
O-RING..............................
2
UOC:V53
5 PAFZZ 5331011067288 81349 M83248/2-218
O-RING..............................
2
UOC:V53
6 PFFZZ 4730010515256 11083 1P4577
FLANGE,PIPE.........................
4
UOC:V53
7 PAFZZ 5310001174788 11083 5M2894
WASHER,FLAT......................... 26
UOC:V53
8 PAFZZ 5305000680511 80204 B1821BH038C125N
SCREW,CAP,HEXAGON H.................
8
UOC:V53
9 AFFZZ
11083 3V0188
HOSE ASSY...........................
1
UOC:V53
10 PAFZZ 4730010517601 11083 3S8503
.ELBOW,FLANGE TO HOS................
1
UOC:V53
11 PAFZZ 3120002361319 11083 3S7252
.SLEEVE.............................
2
UOC:V53
12 MFFZZ
11083 8S9355-AS
.HOSE,SPECIAL MAKE FROM HOSE P/N
V
8S9355..............................
UOC:V53
13 PAFZZ 4730012426344 11083 8S3918
.ADAPTER,STRAIGHT,TU................
1
UOC:V53
14 XBFZZ
32705 307951
DUST COVER..........................
3
UOC:V53
15 PAFZZ 5330009309407 11083 7M8485
SEAL,ADAPTER,MOTOR..................
4
UOC:V53
16 PBFFF 4820012977237 11083 9J4682
VALVE,SAFETY RELIEF.................
1
UOC:V53
17 XAFZZ
11083 9J4683
.BODY,CHECK VALVE...................
1
UOC:V53
18 PAFZZ 4730010667651 11083 0307935
.ADAPTER,STRAIGHT,TU................
4
UOC:V53
19 PAFZZ 5365012971079 11083 1U1576
.PLUG,MACHINE THREAD................
1
UOC:V53
20 PAFZZ 5330009309407 11083 7M8485
.SEAL,ADAPTER,MOTOR.................
1
UOC:V53
21 PAFZZ
11083 9J4751
.SPRING.............................
1
UOC:V53
22 PAFZZ
11083 9J3517
.VALVE..............................
1
UOC:V53
23 PAFZZ 4730010667651 11083 0307935
ADAPTER,STRAIGHT,TU.................
1
