WP 0002 00
TM 10-3930-641-24P
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
SMR
PART
NO
CODE
NSN
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC) QTY
GROUP 0607 INSTRUMENT OR ENGINE
CONTROL PANEL
WIRING HARNESS
1 PAOZZ 5940013034978 11083 5P1475
TERMINAL,LUG........................
4
UOC:V53
2 PFOZZ 5940012855146 79550 412026
TERMINAL,QUICK DISC.................
31
UOC:V53
3 PAOZZ 5935011188884 79550 19189C
CONNECTOR,PLUG,ELEC.................
4
UOC:V53
4 PAOZZ 5940010589112 11083 5P4571
TERMINAL,QUICK DISC.................
1
UOC:V53
5 PAOZZ 5940011036808 11083 5P5694
TERMINAL............................
1
UOC:V53
6 XBOZZ
44655 995-5B-180
RESISTOR............................
1
UOC:V53
7 PAOZA 5999011195999 00779 583362-3
CONTACT,ELECTRICAL..................
15
UOC:V53
8 XBOZZ
00779 583301-1
CONNECTOR...........................
1
UOC:V53
9 PAOZZ 5940010589112 11083 5P4571
TERMINAL,QUICK DISC.................
15
UOC:V53
10 PAOZZ 5940004322660 97403 13216E6191-3
TERMINAL,QUICK DISC.................
7
UOC:V53
END OF FIGURE
