WP 0002 00
TM 10-3930-641-24P
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
SMR
PART
NO
CODE
NSN
CAGEC
NUMBER
DESCRIPTION AND USABLE ON CODES(UOC) QTY
GROUP 12 BRAKES
GROUP 1201 HANDBRAKES
1 XDFZZ
11083 8K1691
HOSE ASSY...........................
1
UOC:V53
2 XDFZZ
11083 4V9553
TUBE ASSY...........................
1
UOC:V53
3 XDFZZ
11083 3V0848
GUARD ASSY..........................
1
UOC:V53
4 MFFZZ
11083 3V0849
HOSE ASSY MAKE FROM HOSE P/N 5P178.
1
UOC:V53
5 PAFZZ 4730010950075 11083 4S5414
.SLEEVE,HOSE........................
2
UOC:V53
6 PFFZZ 4730010950833 11083 8S6393
.ELBOW,TUBE TO HOSE.................
1
UOC:V53
7 PFFZZ 4730010950834 11083 1P9919
.ELBOW,TUBE TO HOSE.................
1
UOC:V53
8 PAFZZ 4730011555055 11083 4S3652
TEE,TUBE............................
1
UOC:V53
9 PAFZZ 5340011555280 11083 5M1198
CLAMP,LOOP..........................
1
UOC:V53
10 XDFZZ
11083 3V0851
TUBE ASSY...........................
1
UOC:V53
11 PFFZZ 4730001433941 96906 MS51527A6
ELBOW,TUBE TO BOSS..................
1
UOC:V53
12 PCFZZ 5331008013354 25184 906-737-70
O-RING..............................
2
UOC:V53
13 XDFZZ
11083 7J4026
ELBOW,TUBE TO BOSS..................
1
UOC:V53
END OF FIGURE
