TM 10-3930-641-34-2
BRAKE LINES REMOVAL/INSTALLATION (CONT)
(Sheet 3 of 4)
LOCATION/ITEM
ACTION
REMARKS
REMOVAL
NOTE
NOTE
Cap or plug openings as lines are removed. Tag
See page 5-99 for illustration.
to identify location.
1.
Transmission
Drain.
See TM 10-3930-641-20.
2.
Capscrews and washers
Remove at both ends of line.
3.
Preformed packing
Remove and discard.
NOTE
Some of the hoses and tubing have brackets
and clips supporting them. Remove capscrews,
washers and nuts and remove.
4.
Tube fittings
Disconnect and remove line.
Go on to Sheet 4
5-100
