TM 10-3930-675-24-2
CAB DOOR ASSEMBLY MAINTENANCE - CONTINUED
0240 00
REMOVAL - CONTINUED
2.
Remove locknut (9), two washers (8), screw (7), and door holder (6) from cab door (5). Discard locknut.
5
6
7
8
9
8
3.
Partially open cab door (5) and, with assistance, remove four screws (11) and cab door from vehicle.
DISASSEMBLY
1.
Remove grease fitting (10) from each of two cab door hinges (12).
2.
10
5
11
12
0240 00-2
