TM 10-3930-641-20
SERVICE BRAKE PEDALS REMOVAL/INSTALLATION (CONT)
(Sheet 3 of 7)
REMARKS
LOCATION/ITEM
ACTION
Remove.
wa;her (15), angle assembly (16)'
Remove from lever (2) to release cable (19).
6. Cotter pin (21), two washers (15),
pin (17)
Slide out of bearing (5
7. Shaft (1)
Remove from lever (2).
8. Capscrew (22) and shaft (1)
Remove from bearing retainer (8).
9. Large nut (6) and washer (7) on
inside of pedal
Remove from other side of bearing retainer (8).
10. Large nut (6) and washer (7) on
outside of pedal
Go on to Sheet 4
2-348
