TM 10-3930-641-34-1
CYLINDER HEADS DISASSEMBLY/ASSEMBLY
(Sheet 1 of 8)
This task covers: Disassembly, inspection and assembly of cylinder head.
INITIAL SETUP
Test Equipment
Materials/Parts
Troubleshooting Reference
As required.
None
Feeler gages
Spacer plate gasket
Straight edge
Equipment Condition
Cylinder head assembly removed.
Special Tools
Personnel Required
None
One mechanic
References
General Safety Instructions
Injection nozzles removal/installation, page 3-29.
Cylinder head weights 200 lbs. (90.7 Kg);
Valves removal/installation, page 3-255.
handle with a hoist.
Engine specifications, page 2-69
Valve guides removal/installation, page 3-262.
Valve seat inserts removal/installation, page 3-260
Cylinder heads removal/installation, page 3-217.
Go on to Sheet 2
3-231
