TM 10-3930-675-10-2
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) - CONTINUED
0013 00
Table 1. Preventive Maintenance Checks and
Services (PMCS) for RTCH-RT 240V2 - Continued.
LOCATION
ITEM TO
ITEM
CHECK/
NOT FULLY MISSION
NO.
INTERVAL
SERVICE
PROCEDURE
CAPABLE IF:
33
After
Rear Fenders, a. Check rear fenders for damage or
missing parts.
Lights, and
Backup
Alarm
b. Check all light assemblies and backup Lights or backup alarm are
alarm for damage.
damaged.
34
After
Folding Step
Check for damage or missing parts.
and Ladder
35
After
Hydraulic
a. Check for damage and leaks.
Class III leaks are evident.
Reservoir and
Sight Gage
NOTE
Boom must be fully lowered and retracted and RTCH parked on
level ground before checking hydraulic oil level in reservoir.
Engine should be stopped at least five minutes.
b. Check hydraulic oil in the oil level sight Hydraulic oil level is below
gage. If hydraulic oil is visible in sight sight gage.
gage, level is okay. If level is low, before
adding oil, remove one of the fill plugs
from the oil filter cover plates at the top of
the hydraulic oil tank and allow the RTCH
to rest another five minutes. Recheck the
oil level. If level is still low, add oil only
through one of the fill points. Refer to add
oil IAW instructions in WP 0012 00.
HYDRAULIC RESERVOIR
DO NOT
FILL
THROUGH
THIS
SIGHT
PORT
GAGE
FILL
DO NOT FILL
POINTS
THROUGH THIS PORT
0013 00-9
